1.25inch - 5inch
Ruixin
Diamond Tubing Broach Slickline
Alloy Steel&Nickel Alloy
China Baoji
Wireline & Slickline
Standard
The Diamond Tubing Broach Slickline are are used to remove or broach tight spots in tubing strings using hardened cutting teeth to cut or shear materials from the tubing wall.
The Diamond Tubing Broach Slickline Depending on the type of material on the tubing well, cutting ability will vary. Broaching tools are usually supplied with a set of cutting mandrels, sized from the restricted ID to the required ID.The tools are available with customer specified connections and fish neck.
OD. | Fishing neck | Connection |
1.25＂-1.5＂ | 1.187＂ | 15/16-10UN |
1.5＂-2＂ | 1.375＂ | 15/16-10UN |
2＂-2.5＂ | 1.375＂ | 15/16-10UN |
2.5＂-3＂ | 1.75＂ | 1-1/16-10UN |
3＂-4＂ | 1.75＂ | 1-1/16-10UN |
4＂-5＂ | 2.313＂ | 1-9/16-10UN |
Note: More customized parts are available upon request.
The Diamond Tubing Broach Slickline use diamond shaped teeth to remove scale, debris, or deformations from the inside of the tubing string.
Diamond Tubing Broach Slickline are similar in design to the conventional type, are heavy-duty tools with hardened and tempered, segmented cutting mandrel sets, which collapse if the tool gets stuck, preventing potential fishing operations.
The Diamond Tubing Broach Slickline are are used to remove or broach tight spots in tubing strings using hardened cutting teeth to cut or shear materials from the tubing wall.
The Diamond Tubing Broach Slickline Depending on the type of material on the tubing well, cutting ability will vary. Broaching tools are usually supplied with a set of cutting mandrels, sized from the restricted ID to the required ID.The tools are available with customer specified connections and fish neck.
OD. | Fishing neck | Connection |
1.25＂-1.5＂ | 1.187＂ | 15/16-10UN |
1.5＂-2＂ | 1.375＂ | 15/16-10UN |
2＂-2.5＂ | 1.375＂ | 15/16-10UN |
2.5＂-3＂ | 1.75＂ | 1-1/16-10UN |
3＂-4＂ | 1.75＂ | 1-1/16-10UN |
4＂-5＂ | 2.313＂ | 1-9/16-10UN |
Note: More customized parts are available upon request.
The Diamond Tubing Broach Slickline use diamond shaped teeth to remove scale, debris, or deformations from the inside of the tubing string.
Diamond Tubing Broach Slickline are similar in design to the conventional type, are heavy-duty tools with hardened and tempered, segmented cutting mandrel sets, which collapse if the tool gets stuck, preventing potential fishing operations.
