Pear Drop Rope Socket Wireline

A pear drop rope socket wireline is used to attach wireline to the tool string. The pear drop rope socket is the most convenient model, which clamps the wireline by the pear-shaped wedge.
Availability:
  • 1.25inch 1.75inch 1.875inch 2.125inch 2.5inch

  • RuiXin

  • Pear Drop Rope Socket Wireline

  • Cast aluminum

  • China Baoji

  • Wireline Operation And Slickline Operation

  • Standard

Pear Drop Rope Socket Wireline Manufacturer - Ruixin

The rope socket is used to securely attach wireline to the toolstring.

Pear Drop Rope Socket Wireline Overview

A pear drop rope socket wireline is used to attach wireline to the tool string. The pear drop rope socket is the most convenient model, which clamps the wireline by the pear-shaped wedge.

Pear Drop Rope Socket Wireline Parameters

Size

Applicable tubing

Applicable wireline

Fishing neck

Connection

1.25"

2-3/8"

0.125″

1.187"

15/16UN

1.5"

2-3/8"~2-7/8"

0.125″

1.375"

15/16UN

1.5"

2-3/8"~2-7/8"

0.16″

1.375"

15/16UN

1.75"

2-3/8"~2-7/8"

0.125″

1.375"

15/16UN

1.875"

2-7/8"~3-1/2"

0.125″

1.75"

1-1/16UN

2.125"

3-1/2"~4-1/2"

0.125″

1.75"

1-1/16UN

2.5"

Over 4-1/2"

0.125″

2.313"

1-9/16UN


Note. More customized parts are available upon request.

Pear Drop Rope Socket Wireline Method of application

1. Pass the steel wire through the body of rope socket and the lock sleeve;

2. Bend the head of steel wire (the shape and size is similar to that of lockpin);

3. Clamp lockpin on the head of bended head of steel wire;

4. Use the lock sleeve to sleeve it so that the steel wire is clamped in the lcokpin and lock sleeve;

5. Lift the steel wire upward to pull the lockpin and lock sleeve into the body of the rope socket;

6. Connect the tool string at the bottom of the body to enter the well. from

Note: because the rope socket is influenced by the weight of tool string, there is a sliding friction between the lock sleeve and body, so the bottom of the rope socket can be connected with the rotating joint to prevent the steel wire from twisting.

Pear Drop Rope Socket Wireline Maintenance:

1. Regularly inspect that whether the lockpin and lock sleeve are damaged or deformed and change them in time;

2. After using the steel wire for a period of time, cut off a length of the head and make a new rope socket head to avoid that the steel wire end is over fatigued to cause the steel wire to be broken.


Best pear drop rope socket -Ruixin
