Pump Connector

The pump connector is a tool connected to the end of the lower well pipe string or fluid control device. When the upper part of the pump connector is pressurized from the ground to the flushing pressure, the overflow channel can be opened, so that the pump connector can be connected up and down for later oil and gas well maintenance.
Availability:
  • 2inch - 4inch

  • Ruixin

  • Pump Connector

  • Alloy Steel&Nickel Alloy

  • China Baoji

  • Wireline Operation And Slickline Operation

  • Standard

Pump Connector Manufacturer - Ruixin

The pump connector is a tool connected to the end of the lower well pipe string or fluid control device. When the upper part of the pump connector is pressurized from the ground to the flushing pressure, the overflow channel can be opened, so that the pump connector can be connected up and down for later oil and gas well maintenance.

Pump Connector Technical parameters of common specifications

Szie

FN

Connection

2″

1.375″

15/16″-10UN

2.5″

1.375″

15/16″-10UN

3″

1.75″

1-1/16″-10UN

3.5″

2.313″

1-1/16″-10UN

4″

2.313″

1-1/16″-10UN

Technical parameters can also be according to user requirements

Pump Connector Structural characteristics

The pump connector part of the adapter is connected with a pipe string or a fluid control device, and the lower part is connected with the body, and together with the plug, it forms the shell of the tool. The sealing sleeve is matched with the plunger and installed in the body to play a sealing role.

Pump Connector Maintenance

1. After the tool is disassembled, the damage of each part should be checked, and the damaged parts should be replaced.

2. When assembling, a thin layer of grease should be applied to the thread surface.

3. After assembly, make a mark and store it for later use.
