2inch - 2.813inch
Ruixin
Slickline B Shifting Tool
Alloy Steel&Nickel Alloy
China Baoji
Wireline Operation And Slickline Operation
Standard
The Slickline B Shifting Tool is used to place the A and X-type closed sliding sleeves in the open or closed position.
Slickline B Shifting Tool， which can shift XA, RA, XO, XD, A, C, CB, WB, L and CM-type sliding sleeves.
The selection key can be used as a non-self-release type but released by a shear pin.
Slickline B Shifting Tool cannot pass through the first S-type seating joint.
Size | Fishing neck | Connection |
2＂ | 1.375＂ | 15/16-10UN |
2.5＂ | 1.75＂ | 15/16-10UN |
2.313＂ | 1.75＂ | 15/16-10UN |
2.813＂ | 2.313＂ | 1-1/16-10UN |
Any size can be customized according to customer requirements
1. Before going down the well, check whether the sealing ring, sealing assembly, and the opening and closing of the balance rod are in good condition.
2. After use, apply grease for dustproof storage, and the sealing assembly is separately greased for storage.
The Slickline B Shifting Tool is used to place the A and X-type closed sliding sleeves in the open or closed position.
Slickline B Shifting Tool， which can shift XA, RA, XO, XD, A, C, CB, WB, L and CM-type sliding sleeves.
The selection key can be used as a non-self-release type but released by a shear pin.
Slickline B Shifting Tool cannot pass through the first S-type seating joint.
Size | Fishing neck | Connection |
2＂ | 1.375＂ | 15/16-10UN |
2.5＂ | 1.75＂ | 15/16-10UN |
2.313＂ | 1.75＂ | 15/16-10UN |
2.813＂ | 2.313＂ | 1-1/16-10UN |
Any size can be customized according to customer requirements
1. Before going down the well, check whether the sealing ring, sealing assembly, and the opening and closing of the balance rod are in good condition.
2. After use, apply grease for dustproof storage, and the sealing assembly is separately greased for storage.
