2.375inch - 4.5inch
Ruixin
Tubing Stop
Alloy Steel&Nickel Alloy
China Baoji
Wireline & Slickline
Standard
A type tubing stop , as the name implies, is a seater that is seated on the inner wall of the oil pipe to fix the pressure gauge.
Size | Fishing | connection |
2-3/8＂ | 1.375＂ | 15/16UN |
| 2-7/8＂ | 1.375＂ | 15/16UN |
3-1/2＂ | 2.313＂ | 1-1/16UN |
4-1/2＂ | 2.313＂ | 1-1/16UN |
Note: Special specifications can be provided according to customer requirements.
1. The Tubing Stop must be connected and fed by the corresponding running tool when going down the well;
2. When the tool is lowered, the slips are in a retracted state, which makes the tool move down smoothly;
3. When the tool reaches the predetermined seating position, shock the tool downward to make the slips open and bite the inner wall of the oil pipe to fix the pressure gauge and prevent movement.
1. When using, carefully check whether the parts are connected well and whether the accessories are loose, so as to prevent the parts from falling off when going down the well, causing unnecessary trouble.
2. When not in use temporarily, clean the tool and store it in a dry place to prevent rust.
