1.5inch 2inch 2.5inch 3inch 4inch
Ruixin
Flopetrol Cutter Wireline
Alloy Steel&Nickel Alloy
China Baoji
Wireline & Slickline
Standard
Flopetrol Cutter Wireline When downhole tools are stuck and cannot be recovered, Use this tool to cut the steel wire or wire rope from the head of the rope socket.
Size | OD | Fishing | Applicable wire |
1.5＂ | 1.5＂ | 1.375＂ | 0.092＂,0.108＂,0125＂ |
1.875＂ | 1.875＂ | 1.75＂ | 0.092＂,0.108＂,0125＂ |
2＂ | 2＂ | 1.75＂ | 0.108＂,0125＂ |
1.The knotted or deformed steel wire will not be cut off incorrectly, which can reduce the risk of misoperation.
2. The tool can effectively cut downhole wires or wire ropes at a place (25mm) close to the head of the rope socket.
3. Replacing taper sleeve can cut wires or wire ropes of different specifications, and can cut up to 1/4 "(6.4 mm) wire ropes.
4. The wire head can be bent after cutting the wire or the wire rope, and the wire can be taken out together with the tool when the wire is pulled out.
1.Unscrew the tool holder and punch out the straight sleeve. The taper sleeve can be
2.changed as required. Pay attention to its positional relationship when installing the blade and tool holder.
3. After use, clean up in time and maintain carefully to prolong the service life of tools.
